Dawopu Design and Manufacturing delivers innovative solutions to manufacturers through product design, engineering, and manufacturing of precision components and assemblies. Our experience covers a wide range of applications that require tight-tolerance fabrication. Primary industries served include medical, appliance, HVAC, engineering,Machinery,and office furniture manufacturers.
But our real value is in bringing our design and manufacturing experience to bear to improve profit margins and delivery times for our clients. Two ways in which we accomplish these objectives are through cnc ,rapid prototyping and 3D laser welding.
Materials and special materials that we turn and mill
Material overview
Anti-magnetic steel
These stainless austenitic steels are characterized by high strength and corrosion resistance, even against salt water, and cannot be magnetized due to the alloy with manganese or molybdenum. Non-magnetizable steel is also known as submarine steel.
Typical material numbers are
Currency no. Short name Identifier. 1.3948 X4CrNiMnMoN 19 13 8 1.3952 X2CrNiMoN 18 14 1.3957 X2CrNiMoNbN 21 15 1.3964 X2CrNiMnMoNNb 21 16 5 3 1.3974 X3CrNiMoNbN 23 17
High temperature resistant
Heat-resistant ferritic steel can withstand high thermal loads and, thanks to its alloying with chromium, silicon and aluminum, retains its good strength properties even when exposed to hot gases and combustion products.
Typical material numbers are
Currency no. Short name Identifier. 1.4713 X10CrAl 7 Sicro 8 1.4724 X10CrAl 13 Sicro 9 1.4742 X10CrAl 18 Sicro 10 1.4762 X10CrAl 24 Sicro 12 1.4821 X20CrNiSi 25 4 1.4828 X15CrNiSi 20 12 1.4841 X15CrNiSi 25 20 1.4864 X12NiCrSi 36 16 1.4878 X12CrNiTi 18 9
Noble be the steel
Chromium-nickel steels with high corrosion resistance and strength are referred to as rust and acid-resistant. They are also referred to as stainless steel, other designations are V2A or V4A. The chromium content of the stainless steel (min. 12 %) forms a wafer-thin layer of chromium oxide in combination with oxygen from air, water or other media. This protects the steel underneath. If the layer is damaged, it forms again.
Typical material numbers are
Currency no. Short name Identifier. 1.4001 X7Cr 14 1.4006 X10Cr 13 C 1 1.4016 X6Cr 17 F 1 1.4021 X20Cr 13 B 1.4024 X15Cr 13 1.4028 X30Cr 13 1.4034 X46Cr 13 VB 1.4057 X20CrNi 17 2 C 3 1.4104 X12CrMoS 17 C 4 1.4106 X10CrMo 13 1.4112 X90CrMoV 18 1.4120 X20CrMo 13 VA 1.4122 X35CrMo 17 BL 1.4301 X5CrNi 18 10 A2 1.4305 X10CrNiS 18 9 MH 1.4306 X2CrNi 19 11 AN 1.4311 X2CrNiN 18 10 1.4313 X4CrNi 13 4 BE 1.4361 X1CrNiSi 18 15 1.4401 X5CrNiMo 17 12 2 A4 1.4404 X2CrNiMo 17 13 2 1.4418 X4CrNiMo 16 5 1.4429 X2CrNiMoN 17 13 3 1.4435 X2CrNiMo 18 14 3 1.4436 X5CrNiMo 17 13 3 1.4438 X2CrNiMo 18 16 4 1.4439 X2CrNiMoN 17 13 5 AM 1.4449 X5CrNiMo 17 13 1.4460 X4CrNiMo 27 5 2 U 1.4462 X2CrNiMoN 22 5 3 T 1.4465 X1CrNiMoN 25 25 2 1.4505 X4NiCrMoCuNb 20 18 2 1.4510 X6CrTi 17 1.4511 X6CrNb 17 1.4528 X105CrCoMo 18 2 1.4529 X1NiCrMoCuN 25 20 6 1.4539 X1NiCrMoCuN 25 20 5 B6 1.4541 X6CrNiTi 18 10 A2 1.4542 X5CrNiCuNb 17 4 1.4548 X5CrNiCuNb 17 4 4 1.4550 X6CrNiNb 18 10 AB 1.4571 X6CrNiMoTi 17 12 2 A4 1.4573 X10CrNiMoTi 18 1 2 1.4577 X3CrNiMoTi 25 25 1.4580 X6CrNiMoNb 17 12 2 AE 1.4582 X4CrNiMoNb 25 7 1.4586 X5NiCrMoCuNb 22 18
Heat resistant
High-temperature steel is specially alloyed and is characterized by the fact that it largely retains its material properties (strength, elasticity) even at high temperatures.
Typical material numbers are
Currency no. Short name Identifier. 1.4913 X19CrMoVNbN 11 1 VW 1.4921 X19CrMo 12 1 M 1.4922 X20CrMoV 12 1 1.4923 X22CrMoV 12 1 V 1.4926 X21CrMoV 12 1 1.4961 X8CrNiNb 16 13 1.4980 X5NiCrTi 26 15 SD 1.4981 X8CrNiMoNb 16 16 O 1.4986 X8CrNiMoBNb 16 16 S
Permanent
Engineering steel is used where higher strength is required (e.g. chrome-molybdenum steel) and/or to replace steel grades that are to be protected against rust by galvanic protection, galvanizing or painting. (VA steel)
Typical material numbers are
Currency no. Short name Identifier. 1.0501 C 35 Y 1.0503 C 45 1.0601 C 60 1.1181 Ck 35 YK 1.1191 Ck 45 1.1221 Ck 60 1.5415 15Mo 3 1.6580 30CrNiMo 8 1.6582 34CrNiMo 6 1.7015 15Cr3 1.7131 16MnCr 5 F 1.7218 25CrMo 4 1.7220 34CrMo 4 DC 1.7225 42CrMo 4 1.7228 50CrMo 4 1.7258 24CrMo 5 G 1.7707 30CrMoV 9 DA 1.7709 21CrMoV 5 7 GA 1.7733 24CrMoV 5 5 H
Everything but iron
Non-ferrous metals are all metals that do not contain iron as the main element. Common examples are copper alloys such as Kuprodur, aluminum alloys or magnesium alloys. Non-ferrous metals are also included.
Typical material numbers are
Currency no. Short name Identifier. 2.0060 E-Cu 2.0321 CuZn37 Cu 2 2.0401 CuZn39Pb3 Cu 3 2.0540 CuZn35Ni 2.0580 CuZn40MnPb Cu 6 2.0730 CuNi12Zn24 2.0872 CuNi10Fe 2.0882 CuNi30Fe 2.0936 CuAI10Fe 2.0966 CuAI10Ni 2.1020 CuSn6 2.1030 CuSn8 3.1645 AICuMgPb 3.2315 AIMgSi1 AI 2 3.3535 AIMg3 AI 1
Conductive and sliding
Kuprodur® (= brand name of Herm. Sprenger Metallwarenfabrik, there is also the Carodur® brand from Buntmetall Amstetten, both are also known as cupronickel silicon) is an alloy of copper, nickel and silicon that combines high strength and hardness with very good corrosion resistance. Kuprodur also has high electrical conductivity, conducts heat well, is durable and shows little wear.
Kuprodur screws and fasteners made of Kuprodur® are therefore used in mechanical and electrical engineering for connections and electrical contacts that are exposed to the elements or subject to high mechanical stress. In vehicle construction, Kuprodur is used for valve guide bushes and is also suitable as a bearing bush for plain bearings subject to high thermal loads.
Currency no. Short name Identifier. 2.0853 CuNi1.5Si Cu 5 (Kuprodur) 2.0855 CuNi2Si (Kuprodur)
Special materials
Special materials are characterized by their suitability for very specific tasks. When it comes to extreme operating temperatures, maximum strength or when the operating conditions are particularly stressful or corrosive, special materials are required. Some special materials also have impressive qualities when it comes to lightweight construction.
The extremely high resistance to certain challenges is typical of many special materials. The processing of these superalloys is correspondingly demanding and requires comprehensive expertise and adapted CNC technology.
Permanent EdeL
Ferralium® Alloy 255, a Langley Alloys brand, is a stainless steel with particularly high strength and very good corrosion resistance.
Currency no. Short name Identifier. Ferralium Alloy 255
Active in the resistance
Hastelloy® is a brand name of Haynes International for high-resistance alloys with a high nickel content. Depending on the alloy, the material is optimized for heat resistance or corrosion resistance.
Currency no. Short name Identifier. 2.4602 NiCr21Mo14W Hastelloy C 22 2.4610 NiMo16Cr16Ti Hastelloy C 4 2.4617 NiMo28 Hastelloy B 2 2.4619 NiCr22Mo7Cu Hastelloy G3 2.4665 NiCr22Fe18Mo Hastelloy X 2.4810 NiMo30 Hastelloy B 2.4819 NiMo16Cr15W Hastelloy C 276
At home in chemistry
Incoloy® is a brand of the Inco Company and stands for highly resistant nickel-iron-chromium alloys, which are used in particular in chemical and petrochemical process engineering.
Currency no. Short name Identifier. 1.4876 X10NiCrAITi 32 20 Incoloy 800H
For the extremes
Inconel® is a trademark of Special Metals Corporation for corrosion-resistant nickel-based alloys suitable for high-temperature applications in extreme environments.
Currency no. Short name Identifier. 1.4563 X1NiCrMoCuN 31 27 4 Inconel 28 2.4663 NiCr23Co12Mo Inconel 617 2.4668 NiCr19NbMo Inconel 718 2.4669 NiCr15Fe7TiAI Inconel X 750 2.4816 NiCr15Fe Inconel 600 2.4851 NiCr23Fe Inconel 601 2.4856 NiCr22Mo9Nb Inconel 625 2.4858 NiCr21Mo Inconel 825
Extremely acid-resistant
Monel® is a brand name of Special Metals Corporation for nickel-copper alloys with high strength and extreme corrosion resistance, for example to media such as seawater, hydrofluoric acid or sulphuric acid.
Currency no. Short name Identifier. 2.4360 NiCu30Fe Monel 400 2.4375 NiCu30AI Monel K 500
Thermally stable
Nickel alloys have very good corrosion resistance and are resistant to high temperatures. They exhibit low thermal expansion.
Currency no. Short name Identifier. 2.4066 Ni 99.2 Nickel 200 2.4068 LC-Ni 99 Nickel 201 Niobium
Nickel inside
Nimonic® is a brand name of Special Metals Corporation for tensile nickel-chromium alloys with high corrosion and oxidation resistance.
Currency no. Short name Identifier. 2.4951 NiCr20Ti Nimonic 75 2.4952 NiCr20TiAI Nimonic 80A
Chemical specialist
Tantalum is a heavy metal that is twice as dense as steel. Tantalum conducts heat and electricity very well and is resistant to heat. Its melting point is just over 3,000° C. Together with its high hardness and corrosion resistance, these properties make tantalum the ideal material for components in the chemical industry. Tantalum components are also used in electronics and automotive engineering.
Customized production
Titanium has a low density and high tensile strength. The material is around 40 % lighter than steel, but achieves similar tensile strengths. Titanium is also highly corrosion-resistant and anti-magnetic.
Currency no. Short name Identifier. 3.7025 Ti 99.8 Titanium size 1 3.7035 Ti 99.7 Titanium size 2 3.7035Pd Ti 99.7 + Pd Titanium Gr. 2 (+ Pd) 3.7055 Ti 99.6 Titanium size 3 3.7165 TiAI6V4 Titanium size 5
Your CNC professionals
Zirconium is a heavy metal that is very difficult to process in zirconium compounds such as zirconium. We manufacture: Zirconium screws, zirconium turned parts,
Currency no. Short name Identifier. Zirconium Circ. 702
